General
| Product Code |
AIN-00025 |
| Model Number |
AI-2CD2547G2-LS |
| Brand |
AINSEN |
| Category |
CAMERAS AND SURVEILLIANCE |
| Weight |
Approx. 400 g (0.9 lb.) |
| Dimensions |
Height approx. 72.6 mm |
| IP Rating |
IP67, IK08 (vandal resistant) |
| Dimension |
Height approx. 72.6 mm |
| Package Weight |
Approx. 635 g (1.4 lb.) |
| Humidity |
95% or less (non-condensing) |
| Certifications |
CE, FCC, UL, RCM, IC |
| White Light Range |
Up to 30 m |
| Iris Type |
Fixed |
| Depth of Field |
2.8 mm: 2.3 m to ∞ / 4 mm: 3.2 m to ∞ |
| BLC / HLC |
Yes |
| Perimeter Protect. |
Line crossing, intrusion, region entrance/exit (human and vehicle triggered) |
| Users |
Up to 32 — 3 levels: administrator, operator, user |
| Operating Temp |
-30 °C to 60 °C (-22 °F to 140 °F) |
Lens
| Lens Type |
Fixed focal lens, 2.8 mm and 4 mm optional |
| Lens Mount |
M16 |
| Aperture |
F1.0 |
| FOV (2.8 mm) |
H: 112°, V: 61°, D: 134° |
| FOV (4 mm) |
H: 95°, V: 47°, D: 115° |
| DORI (2.8 mm) |
D: 58 m, O: 23 m, R: 11 m, I: 6 m |
| DORI (4 mm) |
D: 77 m, O: 30 m, R: 16 m, I: 8 m |
Video
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Max. Frame Rate |
25 fps (50 Hz) / 30 fps (60 Hz) @ 2688 × 1520 |
Audio
| Audio In |
-S: 1 input (line in), max. input amplitude 3.3 Vpp |
| Audio Out |
-S: 1 output (line out), max. output amplitude 3.3 Vpp |
| Audio |
Built-in microphone |
Storage
| On-Board Storage |
microSD/microSDHC/microSDXC, up to 256 GB |
Network
| Network Interface |
1× RJ45 10M/100M Ethernet self-adaptive |
| ONVIF |
Profile S, G, T |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
Alarm
| Alarm I/O |
-S: 1 alarm input / 1 alarm output (max. 12 VDC, 20 mA) |
| Basic Event |
Motion detection (human/vehicle), video tampering, exception |
| Smart Event |
Line crossing, intrusion, region entrance, region exiting, scene change detection |
| Linkage |
Upload to FTP/NAS/memory card, notify surveillance center, trigger recording, trigger capture, send email |
Power
| Power |
12 VDC ±25%, 0.54 A, max. 6.5 W (Ø5.5 mm coaxial, reverse polarity protection) / PoE 802.3af Class 3, 36–57 V, max. 8 W |
*Product performance is based on testing in a controlled environment. Your results may vary.
